Oil pump, electric 230V 9.5L / min oil pressure switch

Self-priming with built in by-pass and pressure switch for controlled oil dispensing. The pressure switch switches the pump on/off automatically when the oil valve is open/closed. Suitable for use with hydraulic oil, gear oil and other lubricating oils.

Technical data

Part No

52520

Capacity

9,5 l/min free flow

Inlet

3/4" (F) BSP

Outlet

1" (F) BSP

Maximum pressure

4 (40) MPa (bar)

Maximum temperature

70 °C

Motor

0,78 kW

Voltage

230 V AC

H.S. Code

84131900

Downloads

• 52510-15-20_EN_SE_ES_1C.pdf
